Digital Temperature Controller (PID Controller) Model No: - R-1005
Digital Temperature Controller (PID Controller)
Model No: - R-1005
RNC’s Digital Temperature Controller ensures precise temperature regulation with reliable performance for industrial and commercial applications.
Applications
- Temperature controllers are used in ovens and in heat-treating applications within furnaces, ceramic kilns, boilers, Acid Baths, Chemical Reactors, heat exchangers & also used in Chemical, Pharmaceuticals, Engineering & Metal Industries.
Product Description
- Model No : R1005 (96X96MM)
- Output : Up to 1 nos. of Relay ( 5 Amp.1 CO),
- Output :1 SSR output (12 V dc)
- Output : O/P 1:- 1 Relay or 1 SSR. For Control O/P PID, ON/OFF.
- Power Supply: 230VAC ± 10 %, 50Hz.
- Range : RTD-PT 100 (0.1° C) - -99.9 to 400.0°C
- Range : RTD-PT 100 (1°C) - -99 to 400°C
- Range : Thermocouple K Type - 0000 to 1200°C
- Range : Thermocouple K Type - 0000 to 650°C
- Resolution :RTD-PT 100 - 1°C or 0.1°C
- Resolution : K Type - 1°C
- Resolution : J Type - 1°C
- Accuracy : Better than ± 0.5 % of Full Scale
- Input : RTD-PT 100 (2W,3W),Thermocouples K Type ,J Type
